Solar cable

Standard Specification for PV Cable with MC4 Connectors

Parameter Specification
Cable Type PV1-F / H1Z2Z2-K Photovoltaic DC Cable
Rated DC Voltage 1500V DC (IEC/EN 62109 compliant)
Test Voltage 6.5kV AC, 5 minutes
Conductor Tinned copper stranded conductor, Class 5 flexible (IEC 60228)
Common Cross-Section 4mm² (AWG11) / 6mm² (AWG10)
Insulation & Sheath Material Cross-linked halogen-free flame-retardant polyolefin (XLPO)
Operating Temperature Range -40°C to +90°C continuous, +120°C short-term
Flame Retardant Property IEC 60332-1/2 single vertical flame test
UV & Weather Resistance UV-stabilized, ozone and weather resistant, ≥25 years outdoor lifespan
MC4 Connector Type Standard PV4 connector, IP67 rated
Connector Rated Current
